3-Step Periscoping Ladder System

SKU: S-1775

316 Stainless Steel

Description 4-Step Configuration
Ladder Length 2' 9-3/8"
Distance between steps 8-7/16"
Storage Bar Length 3' 2-1/8"
Ladder Width (Step) 1' 1-3/4"
Ladder Width (Bar) 3-5/16"
Ladder Depth 2-1/16"
Step Length 5-1/4"
Backbar Depth 2-3/4"
Backbar Width 4"

Featuring all, semi-automatic step deployment.

Hardcoat Anodize for superior corrosion resistance.

Marine grade 316 Stainless Steel hardware.

Back Plate of tube secured with a gasket/backing plate and 4 mounting screws to apply uniform loading.

Removable/replaceable steps via stainless steel shoulder bolt.

Larger faceplate for easier mounting

ABYC compliant (400lb capapcity)
